Description
SW1802** Dual auto switched power module
The SW18 series is the latest generation of socket outlet
designed by CMS Electracom. Softwiring couplers
complying to the AS/NZS61535.1:2003 connector standard
are integrated into the moulding. They comply with IP4X
and hence there is no requirement to use safety end caps
or tool only removable connectors.
The SW18 series offers significant installation benefits as no
tools are required for thin or thick panel mounting. This
speed of installation offers excellent labour savings. The
SW18 series is a 10amp double pole, auto switched outlet.
The SW18 series is covered by the Energy Safe Certificate.
designed by CMS Electracom. Softwiring couplers
complying to the AS/NZS61535.1:2003 connector standard
are integrated into the moulding. They comply with IP4X
and hence there is no requirement to use safety end caps
or tool only removable connectors.
The SW18 series offers significant installation benefits as no
tools are required for thin or thick panel mounting. This
speed of installation offers excellent labour savings. The
SW18 series is a 10amp double pole, auto switched outlet.
The SW18 series is covered by the Energy Safe Certificate.
Features
Double pole auto switched unit
No tools required to install in duct or panel mount,
making site installation very fast and cost effective
making site installation very fast and cost effective
Requires one cut out for thick or thin panel mounting
Slim and compact 2 socket outlet design (only
18.5mm from under face plate)
18.5mm from under face plate)
Integral soft wiring connectors complete with
moulded latches, comply with the new connector
standard AS/NZS/61535.1:2003
moulded latches, comply with the new connector
standard AS/NZS/61535.1:2003
Cut out dimensions
SW1802 - 130.5mm x 41.3mm
SW1802 - 130.5mm x 41.3mm
Colours available
Black, white, red and silver
